Min. reading: 1HLD, 1HV etc. Accuracy ±6HLD (when HLD=800). Display: Leeb(HLD), converted hardness, material etc. Output bluetooth. Supplied with impact device D. Set measurement times
(1~9) to have average value

• Supplied with impact device D
• Set measurement times (1 ~ 9) to have average value
• Based on Leeb (HLD), converted to Vickers (HV), Brinell (HB), Rockwell (HRC &HRB), Shore (HS) and tensile strength (MPa)
• Memory of 99 measurement values for browsing
• Connected with printer via bluetooth
• Automatic power off
• According to ASTM  A 956

Specification

• Min. Reading: 1HLD, 1HV, 1HB, 0.1HRB, 1HS, 1MPa
• Accuracy: ±6HLD (when HLD=800)
• Display: Leeb (HLD), Converted Hardness, Material, Impact Direction, Test Times, Average Value, Date
• Output: Bluetooth
• Applicable Workpiece - Min. Weight: 5kg, 2kg (On Solid Support), 0.1kg (Coupled on Plate)
• Applicable Workpiece - Min. Thickness: 5mm
• Applicable Workpiece - Min. Radius of Curved Surface: 11mm
• Max. Roughness (Ra): 1.6µm
• Power Supply: 3xAAA Batteries
• Dimension (LxWxH): 150x84x28mm
• Weight: 200g



Standard Delivery Includes: Main Unit, Impact Device D, Hardness Test Block, Small Support Ring, Cleaning Brush.
